Outdoor led flood light fixture 50W for landscape for 3 years
warranty.
LED Flood Light-RGB Series
Features:
1. Adopting to high power integrated RGB LED, which ensures light
is more uniform,light efficiency is higher.
2. Standard DMX512 signal input, internal control and external
control.
3. Unique wireless control, control distance up to 50m
4. Built-in 350mA constant current driver design to ensure light
for a stable work
5. Using high transmittance tempered glass,transimittance 93%
6. Complying with ROHS,absolutely not contain mercury or other
harmful substance
7. Lifespan is over 35000 hours
8. May realize "online address grogramming
Applications:
Widely used in various building walls of light color
decoration,stage,meeting rooms,display light, ancient building,
cultural plaza etc.
Parameter Performance:
Material | Die-cast aluminum |
Input Voltage | DC24V |
Power Efficiency | ≥90% |
Beam Angle | 100º 50º |
Led chip | Epistar,Bridgelux,Epileds |
Power(Single LED) | 1W |
LED Qty. | 9/18/30/48 |
Control | DMX512/1990 /RF |
Signal Line | With IP68 waterproof gold-plated terminal connector |
RF Frequency | 335MHz |
RF Distance | 30-50m |
IP Code | IP65 |
Operatinal condition | Temperature:-30℃~50℃
Humidity:10%-90%RH |
Lifespan | >35000hrs |
Technical Data:
Model | Product Dimension(mm) | Power (W) | LED luminous flux | Control mode | N．W |
LY-FL1010RGB-D/R | L120xW95xH130 | 10 | Red: 100-140lm
Green: 200-230lm
Blue:30-50lm | DMX512/RF | 0.51KG |
LY-FL1020RGB-D/R | L205xW157xH250 | 25 | Red: 220-300lm
Green: 400-480lm
Blue:70-110lm | DMX512/RF | 1.8KG |
LY-FL1030RGB-D/R | L205xW157xH250 | 35 | Red: 380-480lm
Green: 680-780lm
Blue:120-180lm | DMX512/RF | 2.03KG |
LY-FL1050RGB-D/R | L250xW180xH310 | 55 | Red: 620-780lm
Green: 1100-1250lm
Blue:200-260lm | DMX512/RF | 2.91KG |
