Technical Data:
| Material | Die-cast Aluminum |
| Input Voltage | AC100-240V 50/60Hz |
| Power Efficiency | ≥85% |
| Power factor | ≥0.95 |
| Beam Angle | 100º 50º |
| LED Luminous efficiency | ≥90lm/W |
| Color Temperature | Warm white WW 2800-3500K
Neutral white NW 4000-5000K
Pure white PW 5500-7000K |
| Detection range | 120º |
| Detection distance | 12m |
| Time-delay | Min:5sec Max:6min±2min |
| Ambient-light | <3Lux-2000Lux |
| Installation | height:2m-4.5m |
| Model | Product Dimension (mm) | Power (W) | LED Luminous flux | Average Iilluminance | Facula Area | Net Weight |
| LY-FL1010PW-P | L115xW85xH106 | 12 | 760-860lm | 1m=289lux
2M=72lux
3M=32lux | 1M=3.5x3.5M
2M=6.5x6.5M
3M=9.5x9.5M | 0.65KG |
| LY-FL1020PW-P | L225xW230xH125 | 25 | 1700-1900lm | 2m=110lux
3M=50lux
4M=30lux | 2M=3.5x3.5M
3M=6.5x6.5M
4M=9.5x9.5M | 2.13KG |
| LY-FL1030PW-P | L225xW230xH125 | 35 | 2550-2850lm | 2m=155lux
3M=75lux
4M=45lux | 2M=3.5x3.5M
3M=6.5x6.5M
4M=9.5x9.5M | 2.14KG |
| LY-FL1050PW-P | L285xW270xH135 | 55 | 4250-4750lm | 4m=80lux
6M=35lux
8M=18lux | 4M=9x9M
6M=14x14M
8M=19x19M | 2.98KG
|
Advantages:
• Adopting high power integrated LED,which ensures light is more
uniform,light efficiency is higher.
• Using high transmittance tempered glass,transimittance93%
• Complying with ROHS,absolutely notcontain mercury or other harmful
substance
• Lifespan of whole tube over 35000hours
• LED lamp turn on automatically whenthe body through the sensor
area.
• Can identify day and night automatically,the ambient-light can be
selected to work at night automatically and stop inthe daytime.
• Time-delay can be adjusted vary to theplace.
Operation and Storage Condition:
• Operation Ambient Temperature -30 to +60°C, Relative Humidity
20~90%
• Input Voltage 100~240V AC, 50/60Hz
• Storage Ambient Temperature -40 to +85°C, Relative Humidity 5~95%
• Mounting Height : Recommend 3-5M height installation.
PIR Sensor LED FLood light on Production:
Installation:
• The entire series of LED flood light are designed with wide range
voltage, the voltage range is 85~264 volts, the frequency is
50/60Hz.
• Installation tool: A adjustable wrench group.
The installation notices
• 1.No necessary using other devices for LED Flood light
installation such as stabilizer, regulator and so on.
• 2.Opening the light and lifting the buckle is unallowable.
Soaking in the water is unallowable.
Applications:
• Suitablefor workshop, factory, garden, road and other automatic
control occasion.
