20 w 30 w 50w IP66 Outdoor waterproof motion sensor smart smd white
led all in one solar street light
01.Features of Led Street Light
1>The intergration of design ,no cable,the installation is very
convenient.
2>The Mono-crystalline solar panel,LED lights,lithium
battery,intelligent controller integrated Aluminum Alloy shell.
3>It used of lithium iron phosphate battery,fight the high
temperature,keep long life.
4>When the products with optically controlled microwave
induction infrared sensor, automatic adjustment of intelligent
power on rainy days, extend rainy days.
5>It used of alloy material as the main structure,with good rust
prevention,corrosion protection.
6>The wireless remote control setting device,adjustable lighting
time ,lighting power ,automatic detection of battery voltage,read
light power parameters,a human body induction function,as long as
people go through when full power lighting,no automatic power down
alf, restore energy saving mode.
7>time control + light sensor control+ motion sensor control
8>Motion and light sensor built in:solar street light goes on at
dusk at 50% brightness. Can go from 50% power to full brightness
when motion is detected. Three Intelligent Modes: Bright / DIM /
Recharge. 1,Bright: motion activates for lighting when motion is
detected for security light and to save battery; 2,DIM: 50%
lighting for saving power when no motion; 3,Off/Recharge:
automatically turns off in daylight and goes into recharge mode.
(working mode can be adjusted according to client's demands).
02.Specifications of Solar Led Street Light
Par NO Parameter | LY-ST30040PW | LY- ST30040WW | LY- ST30040NW |
| Battery | 18650 lithium battery 12V 20 Ah |
| Beam angle | 150x70° | 150x70° | 150x70° |
| Pole diameter | 60MM | 60MM | 60MM |
| Light output | 40W | 40W | 40W |
| Luminous flux(lm) | 5000 | 4000 | 4500 |
| Chip Brand | LUXEON 5050 | LUXEON 5050 | LUXEON 5050 |
| Solar panel | 30W /18V monocrystalline silicon |
| CRI | ＞70 |
| Color Temperature | Warm white:2700-3200K / Neutral white:4000-4500K / Pure
white:5000-6500K |
| Operating time | Full power >12 hours ,Intelligent mode 3-4 days |
| Control Mode | Light Control + Sensor |
| Material | Die Casting Aluminum |
| Luminous efficiency(lm/w) | ＞160 |
| Lifespan(hrs) | ＞50000 |
| IP Rating | IP66 |
| Installation height | 4~8M |
| Size(mm) | 750x257x102 | 750x257x102 | 750x257x102 |
| Net Weigh(kg) | 6.9 | 6.9 | 6.9 |
| Package Size(mm) | 800*295*155 | 800*295*155 | 800*295*155 |
| Package Quantity(Pcs) | 1 | 1 | 1 |
| Gross Weigh(kg) | 7.5 | 7.5 | 7.5 |
03. Application of Led Street Lamp
Suitable for the street lighting; sidewalk lighting;roadway
lighting; fence lighting; pathway lighting; campus lighting; park
lighting; garden lighting;ramp lighting;boat dock lighting; remote
area lighting;farm & ranch lighting.
04.Details of Solar Led Street Lighting
FAQ
Q1. Can I have a sample order for led light?
A: Yes, we welcome sample order to test and check quality. Mixed
samples are acceptable.
Q2. What about the lead time?
A:Sample needs 3-5 days, mass production time needs 1-2 weeks for
order quantity more than
Q3. Do you have any MOQ limit for led light order?
A: Low MOQ, 1pc for sample checking is available
Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5
days to arrive. Airline and sea shipping also optional.
Q5. How to proceed an order for led light?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our
suggestions.
Thirdly customer confirms the samples and places deposit for formal
order.
Fourthly We arrange the production.
Q6. Is it OK to print my logo on led light product?
A: Yes. Please inform us formally before our production and confirm
the design firstly based on our sample.
Q7: Do you offer guarantee for the products?
A: Yes, we offer 3 years warranty to our products.
Q8: How to deal with the faulty?
A: Firstly, Our products are produced in strict quality control
system and the defective rate will be less than 0.2%.
Secondly, during the guarantee period, we will send new lights with
new order for small quantity. Fordefective batch products, we will
repair them and resend them to you or we can discuss the solution
including re-call according to real situation.
