Super Slim 50w dmx rgb color change flood 110v outdoor led Flood
light landscape flood lights
Electrical Specifications
| Model | Power | Input Voltage | LED Qty(pcs) | Beam Angle |
LY-ST23050RGB | 50W | AC100~240V | 28 | 25°/60°/90° |
Photometric Specifications
| Emitting Color | λd / CCT | Typical Lumens | Forward Voltage | Forward Current |
| RED | 620-630 nm | 1400 lm | DC13-17V | 1000mA |
| GREEN | 520-530 nm | 2200 lm | DC21-25V | 1000mA |
| BLUE | 460-465 nm | 560 lm | DC21-25V | 1000mA |
| WHITE | R+G+B | 1500lm | DC13-25V | 1000mA |
Mechanical Specifications
| Model | Carton Size | gross weight | Net Weight | IP Rating | Meterial |
| LY-ST23050RGB | 385X259X155MM | 4.5kg | 3.9kg | IP66 | Aluminum +PC |
Product Details
Features.
Adoption LEYOND exclusive Lens with light transmittance up to 98%.
Perfect Light Distribution Solution:Adoption of integrated shell
optic lens, enhance the brightness and illumination uniformity.
There are 25°,60°, 90° beam angle options for the Lens.
Standard DMX512 input interface and a built-mode controller , can
be realized in whole or segmented light change control, especially,
it can achieve water and complicated effects.
Master or Slave function, if set master, it can stead of the
external controller.
Reliable 350mA constant current driver designed to ensure
high-power LED lights for a stable job.
Superior ability to adapt to the environment, protection grade
IP66, can adapt to a variety of indoor and outdoor temperature and
humidity environment. The lamp base is aluminum alloy, solid
,anti-aging, anti-variant, long service life.
more than 16777 thousand kinds of colors can be realized output,
with good light efficiency, beautiful color and so on.
Impact Resistance, Shock-proof, Without Ultraviolet (UV) and
Infrared (IR) Radiation: No filament and glass frames, avoid break
of the traditional lamp,without harm to the human body.
Distribution Curve
Application
LED is cold light sources, a wide range of output color, RGB LED as
a light source ,can be widely used in various building walls of
light color decoration, and the stage, meeting rooms, display
lights, ancient buildings, the Cultural Plaza and other places.
Our Service:
Payment: T/T in advance
Items: EXW Price
Delivery Time: 5-7 days for sample, 12-18 work days for bulk order.
Shipping way: DHL, FEDEX, UPS, TNT express, by sea or by air.
Quality Control:
Quality guarantee is based on storing,installing,operating and
maintaining correctly in the normal operation condition.
It is not included in our maintaining range when installing
inappropriately,breaking the operating rules,and leading to the
products damaging.
Our company will maintain the right to either repair,parts
replacing,or products exchange during the quality warranty period.
Operation and Storage Condition
1) Operation Ambient Temperature -20 to +50°C, Relative Humidity
20~90%
2) Input Voltage 100~240V AC, 50/60Hz
3) Storage Ambient Temperature -20 to +65°C, Relative Humidity
5~95%
4) Mounting Height : Suitable for 5~12m height
FAQ:
1. May I have a sample for the light please?
---Sure,we welcome sample test.
2. How many watts does this light provide?
---100w, 150w, 200w,250w
3. Which shipping way do you have?
---DHL, FEDEX, UPS and TNT are all support. By sea or by air can be
available based on your request.
4. How many years warranty will you provide?
---5 years warranty.
5. What is the delivery time?
---Normally, 5-7 days for sample, 15-20 days for bulk order. If on
special condition, the delivery time can be discussed.
Thanks for your time! Warmly welcome to inquiry our sales team for
further information. Specification, pricelist and dialux simulation
could be provide if need!
