All in one integrated smart 10w/20w/30w/40w/50w Solar LED light
Features:
1>The intergration of design ,no cable,the installation is very
convenient.
2>The Mono-crystalline solar panel,LED lights,lithium
battery,intelligent controller integrated Aluminum Alloy shell.
3>It used of 18650 lithium battery (lithium iron phosphate
battery),fight the high temperature,keep long life.
4>When the products with optically controlled microwave
induction infrared sensor, automatic adjustment of intelligent
power on rainy days, extend rainy days.
5>It used of alloy material as the main structure,with good rust
prevention,corrosion protection.
6>The wireless remote control setting device,adjustable lighting
time ,lighting power ,automatic detection of battery voltage,read
light power parameters,a human body induction function,as long as
people go through when full power lighting,no automatic power down
alf, restore energy saving mode.
7>time control + light sensor control+ motion sensor control
8>Motion and light sensor built in:solar street light goes on at
dusk at 20% brightness(Brightness adjustable). Can go from 20%
power to full brightness when motion is detected. Three Intelligent
Modes: Bright / DIM / Recharge. 1,Bright: motion activates for
lighting when motion is detected for security light and to save
battery; 2,DIM: 20% lighting for saving power when no
motion(Brightness adjustable); 3,Off/Recharge: automatically turns
off in daylight and goes into recharge mode. (working mode can be
adjusted according to client's demands).
Suitable for the street lighting; sidewalk lighting;roadway
lighting; fence lighting; pathway lighting; campus lighting; park
lighting; garden lighting;ramp lighting;boat dock lighting; remote
area lighting;farm & ranch lighting.
Diagram:
Specification:
Par NO Parameter | LY-ST30050PW | LY- ST30050WW | LY- ST30050NW |
| Battery | 18650 lithium battery 12V 50 Ah |
| Beam angle | 150x65° | 150x65° | 150x65° |
| Pole diameter | 60MM | 60MM | 60MM |
| Light output | 50W | 50W | 50W |
| Luminous flux(lm) | 8120 | 7925 | 8000 |
| Color Temperature | Pure white:5000K | Warm white: 3000K | Neutral white:4000K |
| Solar panel | 50W /18V Sunpower Brand mono crystalline silicon panel |
| CRI | ＞70 |
| Chip Brand | Lumileds Luxeon 5050 |
| Operating time | Full power >24 hours ,Intelligent mode 6-8 days |
| Control Mode | Day Light Control + Sensor |
| Material | Die Casting Aluminum |
| Luminous efficiency(lm/w) | ＞160 |
| Lifespan(hrs) | ＞50000 |
| IP Rating | IP66 |
| Installation height | 4~8M |
| Size(mm) | 945x298x127 | 945x298x127 | 945x298x127 |
| Net Weigh(kg) | 11 | 11 | 11 |
| Package Size(mm) | 1000*340*180 | 1000*340*180 | 1000*340*180 |
| Package Quantity(Pcs) | 1 | 1 | 1 |
| Gross Weigh(kg) | 12.1 | 12.1 | 12.1 |
Distribution Curve
Operation & Storage:
- Option ambient temperature: -30-60 degree Celsius.
- Storage ambient temperature: -20-60 degree Celsius
- Recommended installation height: 4-8 meters
Package Diagram:
Transaction Details:
Payment: T/T in advance
Items: EXW Price
Delivery Time: 5-7 days for sample, 10-15 working days for bulk
quantity.
Shipping way: DHL, FEDEX, UPS, TNT express, by sea or by air.
FAQ:
1. May I have a sample for the light please?
---Sure,mixed power is also support.
2. How many watts does this light provide?
---10w - 50w
3. Which shipping way do you have?
---DHL, FEDEX, UPS and TNT are all support. By sea or by air can be
available based on your request.
4. What is your warranty?
---We are provide 3 years warranty which based on different
materials.
5. What is the delivery time?
---Normally, 5-7 days for sample, 15-20 days for bulk order. If on
special condition, the delivery time can be discussed.
6. Do you make OEM ?
---Yes, OEM orders are warmly welcomed.
7. Are you the manufacturer?
---Yes, we are professional manufacturer for led lighting since
2008. And have completed design-delelop-sales-service system.
