IP66 50W led flood light for outdoor led flood light fixtures.
Lamp drawing:
Applications:
1. It is applicable to playground lighting ,warehouse lighting,
plaza lighting, tunnel lighting and so on.
2. New Installation or Replace the traditional High Pressure Sodium
Lamp, High Pressure Mercury Lamp, and Metal Halide Street Lamps.
Etc.
Features:
1. Adoption LEYOND exclusive Lens with light transmittance up to
98%.
2. Perfect Light Distribution Solution:Adoption of integrated shell
optic lens, enhance the brightness and illumination uniformity.
3. There are 25°,60°, 90° beam angle options for the Lens.
4. Scientifically-designed heat dissipater with much better cooling
effect.
5. High luminous efficiency, Whole lamp output light effiency
>160LM/W.
6. High quality power supply, input voltage 100-240V. The power
efficiency is more than 90%, power factor greater than 0.98,
UL compulsory certification.
7. Impact Resistance, Shock-proof, Without Ultraviolet (UV) and
Infrared (IR) Radiation: No filament and glass frames,
avoid break of the traditional lamp,without harm to the human body.
Specifications:
Par NO Parameter | LY-ST23040PW | LY-ST23040NW | LY-ST23040WW |
| Input voltage | AC100V～240V 50/60HZ |
| System consumption(W) | 40 | 40 | 40 |
| Luminous flux(lm) | 6400 | 6050 | 5600 |
| Chip Brand | LUXEON 5050 LEYOND 5050 | LUXEON 5050 LEYOND 5050 | LUXEON 5050 LEYOND 5050 |
| Beam Angle | 25°,60°, 90° | 25°,60°, 90° | 25°,60°, 90° |
| CRI | ＞75 |
| Color Temperature | WW:2700-3200K / NW:4000-4500K / PW:5000-6500K |
| LED Driver | MEAN WELL ELG-75 / HLG-60H |
| Luminous efficiency(lm/w) | ＞160 |
| Lifespan(hrs) | ＞50000 |
| IP Rating | IP66 |
| Dimmable | YES＆NO | YES＆NO | YES＆NO |
| Size(mm) | 320*128*76 | 320*128*76 | 320*128*76 |
| Net Weigh(kg) | 2.6 | 2.6 | 2.6 |
| Package Size(mm) | 246*390*135 | 246*390*135 | 246*390*135 |
| Package Quantity(Pcs) | 1 | 1 | 1 |
| Gross Weigh(kg) | 3.2 | 3.2 | 3.2 |
