All in one solar LED Garden light 20W with 3 years warranty.
Lamp Drawing:
Features:
1. The integration of design, no cable, the installation is very
convenient.
2. The Mono-crystalline solar panel, LED lights, lithium battery,
intelligent controller integrated Aluminum Alloy shell.
3. It used of 18650 lithium battery (lithium iron phosphate
battery) fight the high temperature, keep long life.
4. When the products with optically controlled microwave induction
infrared sensor, automatic adjustment of intelligent power on rainy
days, extend rainy days.
5. It used of alloy material as the main structure, with good rust
prevention, corrosion protection.
6. The wireless remote control setting device, adjustable lighting
time, lighting power, automatic detection of battery voltage, read
light power parameters, a human body induction function, as long as
people go through when full power lighting, no automatic power down
alf, restore energy saving mode.
7. Time control + light sensor control + motion sensor control
8. Motion and light sensor built in: solar street light goes on at
dusk at 20% brightness (Brightness adjustable). Can go from 20%
power to full brightness when motion is detected. Three Intelligent
Modes: Bright / DIM / Recharge. 1,Bright: motion activates for
lighting when motion is detected for security light and to save
battery; 2,DIM: 20% lighting for saving power when no
motion(Brightness adjustable); 3,Off/Recharge: automatically turns
off in daylight and goes into recharge mode. (working mode can be
adjusted according to client's demands).
Performance Parameter:
Par NO. Parameter | LY-GL10030WW | LY-GL10030NW | LY-GL10030PW |
| Battery | 18650 lithium battery 12V 20 Ah |
| Beam angle | 100°X100° |
| Pole diameter | 60/76/83mm |
| Light output | 30W |
| Luminous flux(lm) | 4050 | 4500 | 4500 |
| Color Temperature | Warm White: 2700-3200K | Neutral White: 4000-4500K | Pure White: 5000-6500K |
| Solar panel | 30W /18V monocrystalline silicon |
| CRI | 70/80/90 |
| Chip Brand | LUXEON 3030 |
| LED Quantity(PCS) | 96 |
| Operating time | Full power >12 hours ,Intelligent mode 3-4 days |
| Control Mode | Light Control + Motion Sensor |
| Material | Die Casting Aluminum |
| Luminous efficiency(lm/w) | 135 | 150 | 150 |
| Lifespan(h) | ＞50000 |
| IP Rating | IP66 |
| Installation height | 3~5M |
Installation Instructions:
1. The ex-factory of the standard components of the LED street lights
include a 3*1mm2 cable .The power supply wire should suffer the
voltage ≥300/500V,the copper cross-section ≥ 0.75 mm2 of 3 copper
wires inside.The installation and wiring connection should be
carried out after turning the power off. Before wiring
connection,the operator must check the polarity of power supply to
prevent the damage of controller fuse and lamp.
2. Insert the street light holder into the pole arm . The diameter of
pole arm is 50 mm.The length of connective part is 60-65mm.Adjust
lamp to desired level ,wrench the M8 secure screws until tightened.
3. Switch on the power and make sure the light is on.Then the
installation is done.
Main Project:
FAQ:
- What about the lead time?
A:Sample needs 7 days, mass production time needs 1-2 weeks for
order quantity more than
- Do you have any MOQ limit for led light order?
A: Low MOQ, 1pc for sample checking is available
- How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5
days to arrive. Airline and sea shipping also optional.
- How to proceed an order for led light?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our
suggestions.
Thirdly customer confirms the samples and places deposit for formal
order.
Fourthly We arrange the production.
- Is it OK to print my logo on led light product?
A: Yes. Please inform us formally before our production and confirm
the design firstly based on our sample.
- Do you offer guarantee for the products?
A: Yes, we offer 5 years warranty to our products.
- How to deal with the faulty?
A: Firstly, Our products are produced in strict quality control
system and the defective rate will be less
than 0.2%.Secondly, during the guarantee period, we will send new
lights with new order for small quantity. For
defective batch products, we will repair them and resend them to
you or we can discuss the solution i
ncluding re-call according to real situation.
