Dimmable Photocell 100W LED Street Lighting Industrial Outdoor
Dimmable Photocell Led Shoebox Module Street Decoration Light Led
Street Light For Road
Application:
Suitable for the street lighting at highways, urban roads and
secondary roads, stadiums,
sidewalk, residential areas, industrial areas, squares, parks,
schools, villas, gardens and other places.
Features
- The shell adopts die-casting integral molding, which has higher
safety and longer life.
- The product has a beautiful appearance and curved lines, which
effectively reduces wind resistance;
- The product has a smooth surface and self-cleaning function, which
effectively reduces dust accumulation;
- Using Philips 5050 lamp beads, the luminous efficiency is as high
as 160lm/w
- The optical lens adopts Japanese PC material, with a light
transmittance of over 93%, anti-ultraviolet rays, and good product
stability;
- The lamp is equipped with a level gauge for positioning, which is
more time-saving and beautiful in installation
- Waterproof and dustproof grade: IP66, protection grade IK10;
- The product is equipped with other more optional functions: light
controller, circuit breaker, single lamp controller, anti-falling
sling, etc.
Specification:
Par NO Parameter | LY-ST80080XX | LY-ST80090XX | LY-ST80100XX | LY-ST80120XX |
| Input voltage | AC100V～277V 50/60HZ / DC12-24V |
| POWER(W) | 80W | 90W | 100W | 120W |
| Luminous flux(lm) | 12000 | 13050 | 14000 | 15600 |
| Chip Brand | LUXEON 3030 |
| LED Quantity (pcs) | 128 |
| Beam Angle | TYPE III 150*80 |
| CRI | 70/80 |
| Color Temperature | Warm white:2700-3200K / Neutral white:4000-4500K / Pure
white:5000-6500K |
| Luminous efficiency(lm/w) | ＞150 | ＞145 | ＞140 | ＞130 |
| LED Driver | MEAN WELL / INVENTRONICS |
| Lifespan(h) | ＞50000 |
| IP Rating / IK | IP66 / IK10 |
| Material | ADC 12 |
| Dimmable | 1-10V/DALI |
| Light body color | Black/Grey |
| working environment | Temperature -20 to +45°C, Relative Humidity 20~90% |
| Storage environment | Temperature -20 to +60°C, Relative Humidity 5~95% |
| Size(mm) | L703*W200*H109mm (L27.68*W7.88*H4.29Inch) |
| Net Weigh(kg) | 4.2 |
| Package Size(mm) | L743*W242*H154mm (L29.25*W9.53*H6.06inch) |
| Package Quantity(Pcs) | 1 |
| Gross Weigh(kg) | 4.9 |
| Installation height(m) | 6-10 |
Distribution Curve (100W)
Outlook:
Package:
| Name | Size | Quantity | N.G | G.W |
| Inner box | L743*W242*H154mm (L29.25*W9.53*H6.06inch) | 1pcs | 4.2kg | 4.9kg |
| Outer box | L760*W254*H332mm L29.92*W10.0*H13.07inch | 2pcs | 8.4kg | 10.3kg |
Notes:
This product provides a 5-year warranty period from the date of
purchase. During the warranty period, if the product fails under
normal use, the company will provide free maintenance services.
During the warranty period, please strictly abide by the product
usage specifications:
1. Before use, please read the installation manual in detail for
correct installation;
2. Please check carefully before use. If any abnormal phenomenon is
found during use, please keep the evidence and contact our company;
3. Please do not disassemble the lamp privately, otherwise it will
be deemed to automatically give up warranty
Projects:
Our Service:
Payment: T/T in advance
Items: EXW Price
Delivery Time: 5-7 days for sample, 10-15 working days for bulk
quantity.
Shipping way: DHL, FEDEX, UPS, TNT express, by sea or by air.
